OgreOggSound::OgreOggISound Class Reference

A single sound object. More...

#include <OgreOggISound.h>

Inheritance diagram for OgreOggSound::OgreOggISound:

Classes
class	SoundListener
	Listener callback. More...

Public Member Functions
void	play (bool immediate=false)
void	pause (bool immediate=false)
void	stop (bool immediate=false)
void	loop (bool loop)
bool	isLooping ()
virtual void	setLoopOffset (float startTime)
float	getLoopOffset ()
virtual void	setSource (ALuint &src)=0
void	startFade (bool dir, float fadeTime, FadeControl actionOnCompletion=OgreOggSound::FC_NONE)
bool	isTemporary () const
virtual bool	isMono ()=0
void	markTemporary ()
void	disable3D (bool disable)
bool	is3Ddisabled ()
virtual void	setPlayPosition (float seconds)
virtual float	getPlayPosition () const
SoundState	getState () const
bool	isPlaying () const
bool	isPaused () const
bool	isStopped () const
bool	isRelativeToListener () const
void	setGiveUpSourceOnStop (bool giveup=false)
void	setPosition (float posx, float posy, float posz)
void	setPosition (const Ogre::Vector3 &pos)
void	setDirection (float dirx, float diry, float dirz)
void	setDirection (const Ogre::Vector3 &dir)
void	setVelocity (float velx, float vely, float velz)
void	setVelocity (const Ogre::Vector3 &vel)
void	setVolume (float gain)
float	getVolume () const
void	setMaxVolume (float maxGain)
float	getMaxVolume ()
void	setMinVolume (float minGain)
float	getMinVolume ()
void	setConeAngles (float insideAngle=360.f, float outsideAngle=360.f)
float	getConeInsideAngle ()
float	getConeOutsideAngle ()
void	setOuterConeVolume (float gain=0.f)
float	getOuterConeVolume ()
void	setMaxDistance (float maxDistance)
const float	getMaxDistance () const
void	setRolloffFactor (float rolloffFactor)
const float	getRolloffFactor () const
void	setReferenceDistance (float referenceDistance)
const float	getReferenceDistance () const
void	setPitch (float pitch)
const float	getPitch () const
void	setRelativeToListener (bool relative)
const Ogre::Vector3 &	getPosition () const
const Ogre::Vector3 &	getDirection () const
bool	isFading () const
virtual void	update (float fTime)
ALuint	getSource () const
const Ogre::String &	getName (void) const
virtual const Ogre::String &	getFileName (void) const
Ogre::uint8	getPriority () const
void	setPriority (Ogre::uint8 priority)
bool	addCuePoint (float seconds)
void	removeCuePoint (unsigned short index)
void	clearCuePoints ()
void	setCuePoint (unsigned short index)
float	getCuePoint (unsigned short index)
unsigned int	getNumCuePoints ()
float	getAudioLength () const
virtual const Ogre::String &	getMovableType (void) const
virtual const Ogre::AxisAlignedBox &	getBoundingBox (void) const
virtual float	getBoundingRadius (void) const
Ogre::SceneManager *	getSceneManager () const
void	setListener (SoundListener *listener)
void	_setSharedProperties (sharedAudioBuffer *buffer)
void	_getSharedProperties (BufferListPtr &buffers, float &length, ALenum &format)
Public Member Functions inherited from Ogre::MovableObject
	MovableObject ()
	MovableObject (const String &name)
virtual	~MovableObject ()
MovableObjectFactory *	_getCreator (void) const
LightList *	_getLightList ()
SceneManager *	_getManager (void) const
virtual const Affine3 &	_getParentNodeFullTransform (void) const
virtual void	_notifyCreator (MovableObjectFactory *fact)
virtual void	_notifyCurrentCamera (Camera *cam)
virtual void	_notifyManager (SceneManager *man)
virtual void	_releaseManualHardwareResources ()
virtual void	_restoreManualHardwareResources ()
void	addQueryFlags (uint32 flags)
void	addVisibilityFlags (uint32 flags)
void	detachFromParent (void)
Real	getBoundingRadiusScaled () const
bool	getCastShadows (void) const
const AxisAlignedBox &	getDarkCapBounds (const Light &light, Real dirLightExtrusionDist) const override
EdgeData *	getEdgeList (void)
const AxisAlignedBox &	getLightCapBounds (void) const override
uint32	getLightMask () const
Listener *	getListener (void) const
const String &	getName (void) const
Node *	getParentNode (void) const
SceneNode *	getParentSceneNode (void) const
Real	getPointExtrusionDistance (const Light *l) const
virtual uint32	getQueryFlags (void) const
bool	getReceivesShadows ()
Real	getRenderingDistance (void) const
Real	getRenderingMinPixelSize () const
uint8	getRenderQueueGroup (void) const
const ShadowRenderableList &	getShadowVolumeRenderableList (ShadowTechnique shadowTechnique, const Light *light, HardwareIndexBufferSharedPtr *indexBuffer, size_t *indexBufferUsedSize, bool extrudeVertices, Real extrusionDist, unsigned long flags=0)
virtual uint32	getTypeFlags (void) const
const Any &	getUserAny (void) const
UserObjectBindings &	getUserObjectBindings ()
const UserObjectBindings &	getUserObjectBindings () const
virtual uint32	getVisibilityFlags (void) const
bool	getVisible (void) const
virtual const AxisAlignedBox &	getWorldBoundingBox (bool derive=false) const
virtual const Sphere &	getWorldBoundingSphere (bool derive=false) const
bool	isAttached (void) const
bool	isDebugDisplayEnabled (void) const
virtual bool	isInScene (void) const
bool	isParentTagPoint () const
virtual bool	isVisible (void) const
const LightList &	queryLights (void) const
void	removeQueryFlags (uint32 flags)
void	removeVisibilityFlags (uint32 flags)
void	setCastShadows (bool enabled)
void	setDebugDisplayEnabled (bool enabled)
void	setLightMask (uint32 lightMask)
void	setListener (Listener *listener)
void	setQueryFlags (uint32 flags)
void	setRenderingDistance (Real dist)
void	setRenderingMinPixelSize (Real pixelSize)
virtual void	setRenderQueueGroup (uint8 queueID)
virtual void	setRenderQueueGroupAndPriority (uint8 queueID, ushort priority)
void	setUserAny (const Any &anything)
void	setVisibilityFlags (uint32 flags)
void	setVisible (bool visible)
Public Member Functions inherited from Ogre::ShadowCaster
virtual	~ShadowCaster ()
virtual ShadowRenderableListIterator	getShadowVolumeRenderableIterator (ShadowTechnique shadowTechnique, const Light *light, HardwareIndexBufferSharedPtr *indexBuffer, size_t *indexBufferUsedSize, bool extrudeVertices, Real extrusionDistance, unsigned long flags=0)
bool	hasEdgeList ()
Public Member Functions inherited from Ogre::AnimableObject
	AnimableObject ()
virtual	~AnimableObject ()
virtual AnimableValuePtr	createAnimableValue (const String &valueName)
const StringVector &	getAnimableValueNames (void) const

Protected Member Functions
	OgreOggISound (const Ogre::String &name, Ogre::SceneManager *scnMgr)
virtual	~OgreOggISound ()
virtual void	_openImpl (Ogre::DataStreamPtr &fileStream)=0
virtual void	_openImpl (const Ogre::String &fName, sharedAudioBuffer *buffer=0)
virtual void	_playImpl ()=0
virtual void	_pauseImpl ()=0
virtual void	_stopImpl ()=0
virtual void	_release ()=0
virtual void	_updateRenderQueue (Ogre::RenderQueue *queue)
virtual void	_notifyAttached (Ogre::Node *node, bool isTagPoint=false)
virtual void	_notifyMoved (void)
virtual void	visitRenderables (Ogre::Renderable::Visitor *visitor, bool debugRenderables)
void	_initSource ()
void	_markPlayPosition ()
void	_recoverPlayPosition ()
void	_updateFade (float fTime=0.f)
virtual void	_updateAudioBuffers ()=0
virtual void	_prebuffer ()=0
virtual bool	_queryBufferInfo ()=0

Protected Attributes
float	mFadeTimer
float	mFadeTime
float	mFadeInitVol
float	mFadeEndVol
bool	mFade
FadeControl	mFadeEndAction
Ogre::DataStreamPtr	mAudioStream
ov_callbacks	mOggCallbacks
SoundListener *	mSoundListener
size_t	mBufferSize
ALuint	mSource
Ogre::SceneManager *	mScnMgr
Ogre::uint8	mPriority
Ogre::Vector3	mPosition
Ogre::Vector3	mDirection
Ogre::Vector3	mVelocity
float	mGain
float	mMaxGain
float	mMinGain
float	mMaxDistance
float	mRolloffFactor
float	mReferenceDistance
float	mPitch
float	mOuterConeGain
float	mInnerConeAngle
float	mOuterConeAngle
float	mPlayTime
Ogre::String	mName
SoundState	mState
bool	mLoop
bool	mDisable3D
bool	mGiveUpSource
bool	mStream
bool	mSourceRelative
bool	mLocalTransformDirty
bool	mPlayPosChanged
bool	mSeekable
bool	mTemporary
bool	mInitialised
Ogre::uint8	mAwaitingDestruction
BufferListPtr	mBuffers
ALenum	mFormat
unsigned long	mAudioOffset
unsigned long	mAudioEnd
float	mLoopOffset
float	mLoopStart
ALfloat	mPlayPos
std::deque< float >	mCuePoints

Friends
class	OgreOggSoundManager

Additional Inherited Members
Public Types inherited from Ogre::ShadowCaster
typedef std::vector< ShadowRenderable * >	ShadowRenderableList
typedef VectorIterator< ShadowRenderableList >	ShadowRenderableListIterator
Static Public Member Functions inherited from Ogre::MovableObject
static uint32	getDefaultQueryFlags ()
static uint32	getDefaultVisibilityFlags ()
static void	setDefaultQueryFlags (uint32 flags)
static void	setDefaultVisibilityFlags (uint32 flags)
Static Public Member Functions inherited from Ogre::ShadowCaster
static void	clearShadowRenderableList (ShadowRenderableList &shadowRenderables)
static void	extrudeVertices (const HardwareVertexBufferSharedPtr &vertexBuffer, size_t originalVertexCount, const Vector4 &lightPos, Real extrudeDist)

Detailed Description

A single sound object.

provides functions for setting audio properties on a 3D sound as well as stop/pause/play operations.

Constructor & Destructor Documentation

OgreOggISound()

OgreOggSound::OgreOggISound::OgreOggISound ( const Ogre::String &  name, Ogre::SceneManager *  scnMgr  )

protected

Superclass describing a single sound object.

Parameters

name	Name of sound within manager
scnMgr	SceneManager which created this sound (if the sound was created through the plugin method createMovableobject()).

~OgreOggISound()

virtual OgreOggSound::OgreOggISound::~OgreOggISound ( )

protectedvirtual

Superclass destructor.

Member Function Documentation

_getSharedProperties()

void OgreOggSound::OgreOggISound::_getSharedProperties	(	BufferListPtr &	buffers,
		float &	length,
		ALenum &	format
	)

Gets properties of a shared resource.

Remarks

Gets a number of properties relating to audio of a shared resource.

Parameters

buffers	Reference to an array of OpenAL buffers
length	Reference to an object to store audio length
format	Reference to an object to store buffer format

_initSource()

void OgreOggSound::OgreOggISound::_initSource ( )

protected

Inits source object

Remarks

Initialises all the source objects states ready for playback.

_markPlayPosition()

void OgreOggSound::OgreOggISound::_markPlayPosition ( )

protected

Stores the current play position of the sound

Remarks

Only for static sounds at present so that when re-activated it begins exactly where it left off.

_notifyAttached()

virtual void OgreOggSound::OgreOggISound::_notifyAttached ( Ogre::Node *  node, bool  isTagPoint = false  )

protectedvirtual

Notifys object its been attached to a node

Remarks

Overridden from MovableObject.

Reimplemented from Ogre::MovableObject.

_notifyMoved()

virtual void OgreOggSound::OgreOggISound::_notifyMoved ( void  )

protectedvirtual

Notifys object its been moved

Remarks

Overridden from MovableObject.

Reimplemented from Ogre::MovableObject.

_openImpl() [1/2]

virtual void OgreOggSound::OgreOggISound::_openImpl ( const Ogre::String &  fName, sharedAudioBuffer *  buffer = 0  )

inlineprotectedvirtual

Open implementation.

Remarks

Abstract function Optional opening function for (Static sounds only)

Reimplemented in OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_openImpl() [2/2]

virtual void OgreOggSound::OgreOggISound::_openImpl ( Ogre::DataStreamPtr &  fileStream )

protectedpure virtual

Open implementation.

Remarks

Abstract function

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_pauseImpl()

virtual void OgreOggSound::OgreOggISound::_pauseImpl ( )

protectedpure virtual

Pause implementation.

Remarks

Abstract function

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_playImpl()

virtual void OgreOggSound::OgreOggISound::_playImpl ( )

protectedpure virtual

Play implementation.

Remarks

Abstract function

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_prebuffer()

virtual void OgreOggSound::OgreOggISound::_prebuffer ( )

protectedpure virtual

Prefills buffers with audio data.

Remarks

Loads audio data from the stream into the predefined data buffers and queues them onto the source ready for playback.

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_queryBufferInfo()

virtual bool OgreOggSound::OgreOggISound::_queryBufferInfo ( )

protectedpure virtual

Calculates buffer size and format.

Remarks

Calculates a block aligned buffer size of 250ms using sound properties.

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_recoverPlayPosition()

void OgreOggSound::OgreOggISound::_recoverPlayPosition ( )

protected

Sets the previous play position of the sound

Remarks

Uses a previously stored play position to ensure sound playback starts where it left off

_release()

virtual void OgreOggSound::OgreOggISound::_release ( )

protectedpure virtual

Release implemenation

Remarks

Cleans up buffers and prepares sound for destruction.

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_setSharedProperties()

void OgreOggSound::OgreOggISound::_setSharedProperties

(

sharedAudioBuffer *

buffer

)

Sets properties of a shared resource.

Remarks

Sets a number of properties relating to audio of a shared resource.

Parameters

buffer

Pointer to the shared buffer to copy the properties from.

_stopImpl()

virtual void OgreOggSound::OgreOggISound::_stopImpl ( )

protectedpure virtual

Stop implementation.

Remarks

Abstract function

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_updateAudioBuffers()

virtual void OgreOggSound::OgreOggISound::_updateAudioBuffers ( )

protectedpure virtual

Updates audio buffers

Remarks

Abstract function.

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

_updateFade()

void OgreOggSound::OgreOggISound::_updateFade ( float  fTime = 0.f )

protected

Updates a fade

Remarks

Updates a fade action.

_updateRenderQueue()

virtual void OgreOggSound::OgreOggISound::_updateRenderQueue ( Ogre::RenderQueue *  queue )

protectedvirtual

Updates RenderQueue

Remarks

Overridden from MovableObject.

Implements Ogre::MovableObject.

addCuePoint()

bool OgreOggSound::OgreOggISound::addCuePoint

(

float

seconds

)

Adds a time position in a sound as a cue point

Remarks

Allows the setting of a 'jump-to' point within an audio file. Returns true on success.

Parameters

seconds

Cue point in seconds

clearCuePoints()

void OgreOggSound::OgreOggISound::clearCuePoints ( )

inline

Clears entire list of cue points

disable3D()

void OgreOggSound::OgreOggISound::disable3D

(

bool

disable

)

Allows switchable spatialisation for this sound.

Remarks

Switch's spatialisation on/off for mono sounds, no-effect for stereo sounds.

Note

If disabling spatialisation, reference distance is set to 1 and Positon is set to ZERO, so may need resetting should spatialisation be re-enabled later.
Note also that node inherited positioning/orientation is disabled in this mode, however manual positioning/orientation is still available allowing some control over speaker output.

getAudioLength()

float OgreOggSound::OgreOggISound::getAudioLength ( ) const

inline

Gets the length of the audio file in seconds

Remarks

Only valid after file has been opened AND file is seekable.

getBoundingBox()

virtual const Ogre::AxisAlignedBox& OgreOggSound::OgreOggISound::getBoundingBox ( void  ) const

virtual

Gets bounding box

Remarks

Overridden from MovableObject.

Implements Ogre::MovableObject.

getBoundingRadius()

virtual float OgreOggSound::OgreOggISound::getBoundingRadius ( void  ) const

virtual

Gets bounding radius

Remarks

Overridden from MovableObject.

Implements Ogre::MovableObject.

getConeInsideAngle()

float OgreOggSound::OgreOggISound::getConeInsideAngle

(

)

Gets sounds cone inside angle

Remarks

This function gets the inside angle (in degrees) of the sound cone used by this sound.

getConeOutsideAngle()

float OgreOggSound::OgreOggISound::getConeOutsideAngle

(

)

Gets sounds cone outside angle

Remarks

This function gets the outside angle (in degrees) of the sound cone used by this sound.

getCuePoint()

float OgreOggSound::OgreOggISound::getCuePoint

(

unsigned short

index

)

Gets a previously set cue point by index

Parameters

index

Position in cue point list to get

getDirection()

const Ogre::Vector3& OgreOggSound::OgreOggISound::getDirection ( ) const

inline

Gets the sounds direction

getFileName()

virtual const Ogre::String& OgreOggSound::OgreOggISound::getFileName ( void  ) const

inlinevirtual

Gets the sounds file name

Reimplemented in OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

getLoopOffset()

float OgreOggSound::OgreOggISound::getLoopOffset ( )

inline

Gets the start point of a loopable section of audio in seconds.

getMaxDistance()

const float OgreOggSound::OgreOggISound::getMaxDistance

(

)

const

Gets sounds maximum distance

Remarks

Returns -1 on error

getMaxVolume()

float OgreOggSound::OgreOggISound::getMaxVolume

(

)

Gets sounds maximum attenuation volume

Remarks

This function gets the maximum volume level of the sound when closest to the listener.

getMinVolume()

float OgreOggSound::OgreOggISound::getMinVolume

(

)

Gets sounds minimum attenuation volume

Remarks

This function gets the minimum volume level of the sound when furthest away from the listener.

getMovableType()

virtual const Ogre::String& OgreOggSound::OgreOggISound::getMovableType ( void  ) const

virtual

Gets movable type string

Remarks

Overridden from MovableObject.

Implements Ogre::MovableObject.

getName()

const Ogre::String& OgreOggSound::OgreOggISound::getName ( void  ) const

inline

Gets the sounds name

getNumCuePoints()

unsigned int OgreOggSound::OgreOggISound::getNumCuePoints ( )

inline

Returns number of cue points

getOuterConeVolume()

float OgreOggSound::OgreOggISound::getOuterConeVolume

(

)

Gets sounds outer cone volume

Remarks

This function gets the volume level heard at the outer cone angle.

getPitch()

const float OgreOggSound::OgreOggISound::getPitch

(

)

const

Gets sounds pitch

Remarks

Returns -1 on error

getPlayPosition()

virtual float OgreOggSound::OgreOggISound::getPlayPosition ( ) const

virtual

Gets the position of the playback cursor in seconds

Reimplemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, and OgreOggSound::OgreOggStreamBufferSound.

getPosition()

const Ogre::Vector3& OgreOggSound::OgreOggISound::getPosition ( ) const

inline

Gets sounds position

getPriority()

Ogre::uint8 OgreOggSound::OgreOggISound::getPriority ( ) const

inline

Gets the sounds priority

getReferenceDistance()

const float OgreOggSound::OgreOggISound::getReferenceDistance

(

)

const

Gets sounds reference distance

Remarks

Returns -1 on error

getRolloffFactor()

const float OgreOggSound::OgreOggISound::getRolloffFactor

(

)

const

Gets sounds rolloff factor

Remarks

Returns -1 on error

getSceneManager()

Ogre::SceneManager* OgreOggSound::OgreOggISound::getSceneManager ( ) const

inline

Gets the SceneManager pointer registered at creation.

Remarks

This will only be set if the sound was created through the plugin method createMovableobject().

getSource()

ALuint OgreOggSound::OgreOggISound::getSource ( ) const

inline

Gets the sounds source

getState()

SoundState OgreOggSound::OgreOggISound::getState ( ) const

inline

Gets the current state the sound is in

getVolume()

float OgreOggSound::OgreOggISound::getVolume

(

)

const

Gets sounds volume

Remarks

Gets the current gain value.

is3Ddisabled()

bool OgreOggSound::OgreOggISound::is3Ddisabled

(

)

Queries switchable spatialisation for this sound.

Remarks

Get whether spatialisation is on/off for mono sounds (for stereo sounds the effect does not apply).

isFading()

bool OgreOggSound::OgreOggISound::isFading ( ) const

inline

Returns fade status.

isLooping()

bool OgreOggSound::OgreOggISound::isLooping ( )

inline

Gets looping status.

Remarks

Gets whether the looping status is enabled

isMono()

virtual bool OgreOggSound::OgreOggISound::isMono ( )

pure virtual

Returns whether this sound is mono

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

isPaused()

bool OgreOggSound::OgreOggISound::isPaused ( ) const

inline

Returns pause status.

Remarks

Checks for a valid source before checking the state value

isPlaying()

bool OgreOggSound::OgreOggISound::isPlaying ( ) const

inline

Returns play status.

Remarks

Checks for a valid source before checking the state value

isRelativeToListener()

bool OgreOggSound::OgreOggISound::isRelativeToListener ( ) const

inline

Returns position status.

Remarks

Returns whether position is local to listener or in world-space

isStopped()

bool OgreOggSound::OgreOggISound::isStopped ( ) const

inline

Returns stop status.

Remarks

Checks for a valid source before checking the state value

isTemporary()

bool OgreOggSound::OgreOggISound::isTemporary ( ) const

inline

Returns whether this sound is temporary

loop()

void OgreOggSound::OgreOggISound::loop ( bool  loop )

inline

Sets looping status.

Remarks

Parameters

loop	Boolean: true == loop

markTemporary()

void OgreOggSound::OgreOggISound::markTemporary ( )

inline

Marks sound as temporary

Remarks

Auto-destroys itself after finishing playing.

pause()

void OgreOggSound::OgreOggISound::pause

(

bool

immediate = false

)

Pauses sound.

play()

void OgreOggSound::OgreOggISound::play

(

bool

immediate = false

)

Plays sound.

removeCuePoint()

void OgreOggSound::OgreOggISound::removeCuePoint

(

unsigned short

index

)

Removes a cue point

setConeAngles()

void OgreOggSound::OgreOggISound::setConeAngles	(	float	insideAngle = 360.f,
		float	outsideAngle = 360.f
	)

Sets sounds cone angles

Remarks

This value sets the angles of the sound cone used by this sound.

Parameters

insideAngle	Angle over which the volume is at maximum (in degrees)
outsideAngle	Angle over which the volume is at minimum (in degrees)

setCuePoint()

void OgreOggSound::OgreOggISound::setCuePoint

(

unsigned short

index

)

Shifts the play position to a previously set cue point position.

Parameters

index

Position in cue point list to apply

setDirection() [1/2]

void OgreOggSound::OgreOggISound::setDirection

(

const Ogre::Vector3 &

dir

)

Sets sounds direction.

Parameters

dir	3D vector direction

setDirection() [2/2]

void OgreOggSound::OgreOggISound::setDirection	(	float	dirx,
		float	diry,
		float	dirz
	)

Sets sounds direction.

Parameters

dirx	x coord
diry	y coord
dirz	z coord

setGiveUpSourceOnStop()

void OgreOggSound::OgreOggISound::setGiveUpSourceOnStop ( bool  giveup = false )

inline

Sets whether source is given up when stopped.

Remarks

This flag indicates that the sound should immediately give up its source if finished playing or manually stopped. Useful for infrequent sounds or sounds which only play once. Allows other sounds immediate access to a playable source object.

Parameters

giveup

If true, releases source immediately (default: false)

setListener()

void OgreOggSound::OgreOggISound::setListener ( SoundListener *  listener )

inline

Sets a listener object to be notified of events.

Remarks

Allows state changes to be signaled to an interested party.

Parameters

listener

Listener object pointer.

setLoopOffset()

virtual void OgreOggSound::OgreOggISound::setLoopOffset ( float  startTime )

inlinevirtual

Sets the start point of a loopable section of audio.

Remarks

Allows user to define any start point for a loopable sound, by default this would be 0, or the entire audio data, but this function can be used to offset the start of the loop.

Parameters

startTime

Position in seconds to offset the loop point.

Note

The sound will start playback from the beginning of the audio data but upon looping, if set, it will loop back to the new offset position.

(Streamed sounds ONLY)

Reimplemented in OgreOggSound::OgreOggStreamWavSound, and OgreOggSound::OgreOggStreamSound.

setMaxDistance()

void OgreOggSound::OgreOggISound::setMaxDistance

(

float

maxDistance

)

Sets sounds maximum distance

Remarks

This value sets the maximum distance at which attenuation is stopped. Beyond this distance the volume remains constant.

Parameters

maxDistance

Distance.

setMaxVolume()

void OgreOggSound::OgreOggISound::setMaxVolume

(

float

maxGain

)

Sets sounds maximum attenuation volume

Remarks

This value sets the maximum volume level of the sound when closest to the listener.

Parameters

maxGain

Volume scalar (0..1)

setMinVolume()

void OgreOggSound::OgreOggISound::setMinVolume

(

float

minGain

)

Sets sounds minimum attenuation volume

Remarks

This value sets the minimum volume level of the sound when furthest away from the listener.

Parameters

minGain

Volume scalar (0..1)

setOuterConeVolume()

void OgreOggSound::OgreOggISound::setOuterConeVolume

(

float

gain = 0.f

)

Sets sounds outer cone volume

Remarks

This value sets the volume level heard at the outer cone angle. Usually 0 so no sound heard when not within sound cone.

Parameters

gain	Volume scalar (0..1)

setPitch()

void OgreOggSound::OgreOggISound::setPitch

(

float

pitch

)

Sets sounds pitch

Remarks

This affects the playback speed of the sound

Parameters

pitch

Pitch (>0).

setPlayPosition()

virtual void OgreOggSound::OgreOggISound::setPlayPosition ( float  seconds )

virtual

Sets the position of the playback cursor in seconds

Parameters

seconds

Play position in seconds

Reimplemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, and OgreOggSound::OgreOggStreamBufferSound.

setPosition() [1/2]

void OgreOggSound::OgreOggISound::setPosition

(

const Ogre::Vector3 &

pos

)

Sets sounds position.

Parameters

pos	3D vector position

setPosition() [2/2]

void OgreOggSound::OgreOggISound::setPosition	(	float	posx,
		float	posy,
		float	posz
	)

Sets sounds position.

Parameters

posx	x position
posy	y position
posz	z position

setPriority()

void OgreOggSound::OgreOggISound::setPriority ( Ogre::uint8  priority )

inline

Sets the sounds priority

Remarks

This can be used to specify a priority to the sound which will be checked when re-using sources. Higher priorities will tend to keep their sources.

Parameters

priority

Priority (between 0..255)

setReferenceDistance()

void OgreOggSound::OgreOggISound::setReferenceDistance

(

float

referenceDistance

)

Sets sounds reference distance

Remarks

This value sets the half-volume distance. The distance at which the volume would be reduced by half.

Parameters

referenceDistance

Distance (>0).

setRelativeToListener()

void OgreOggSound::OgreOggISound::setRelativeToListener

(

bool

relative

)

Sets whether the positional information is relative to the listener

Remarks

This specifies whether the sound is attached to listener or in world-space. Default: world-space

Parameters

relative

Boolean yes/no.

setRolloffFactor()

void OgreOggSound::OgreOggISound::setRolloffFactor

(

float

rolloffFactor

)

Sets sounds rolloff factor

Remarks

This value sets the rolloff factor applied to the attenuation of the volume over distance. Effectively scales the volume change affect.

Parameters

rolloffFactor

Factor (>0).

setSource()

virtual void OgreOggSound::OgreOggISound::setSource ( ALuint &  src )

pure virtual

Sets the source object for playback.

Remarks

Abstract function

Implemented in OgreOggSound::OgreOggStreamWavSound, OgreOggSound::OgreOggStreamSound, OgreOggSound::OgreOggStreamBufferSound, OgreOggSound::OgreOggStaticWavSound, and OgreOggSound::OgreOggStaticSound.

setVelocity() [1/2]

void OgreOggSound::OgreOggISound::setVelocity

(

const Ogre::Vector3 &

vel

)

Sets sounds velocity.

Parameters

vel	3D vector velocity

setVelocity() [2/2]

void OgreOggSound::OgreOggISound::setVelocity	(	float	velx,
		float	vely,
		float	velz
	)

Sets sounds velocity.

Parameters

velx	x velocity
vely	y velocity
velz	z velocity

setVolume()

void OgreOggSound::OgreOggISound::setVolume

(

float

gain

)

Sets sounds volume

Remarks

Sets sounds current gain value (0..1).

Parameters

gain	volume scalar.

startFade()

void OgreOggSound::OgreOggISound::startFade	(	bool	dir,
		float	fadeTime,
		FadeControl	actionOnCompletion = OgreOggSound::FC_NONE
	)

Starts a fade in/out of the sound volume

Remarks

Triggers a fade in/out of the sounds volume over time. Uses the current volume as the initial level to fade from, then either 0 or mMaxGain will be used as the fade to level.

Parameters

dir	Direction to fade. (true=in | false=out)
fadeTime	Time over which to fade (>0)
actionOnCompletion	Optional action to perform when fading has finished (default: NONE)

stop()

void OgreOggSound::OgreOggISound::stop

(

bool

immediate = false

)

Stops sound.

update()

virtual void OgreOggSound::OgreOggISound::update ( float  fTime )

virtual

Updates sund

Remarks

Updates sounds position, buffers and state

Parameters

fTime

Elapsed frametime.

visitRenderables()

virtual void OgreOggSound::OgreOggISound::visitRenderables ( Ogre::Renderable::Visitor *  visitor, bool  debugRenderables  )

protectedvirtual

Renderable callback

Remarks

Overridden function from MovableObject.

Implements Ogre::MovableObject.

Friends And Related Function Documentation

OgreOggSoundManager

friend class OgreOggSoundManager

friend

Member Data Documentation

mAudioEnd

unsigned long OgreOggSound::OgreOggISound::mAudioEnd

protected

mAudioOffset

unsigned long OgreOggSound::OgreOggISound::mAudioOffset

protected

mAudioStream

Ogre::DataStreamPtr OgreOggSound::OgreOggISound::mAudioStream

protected

mAwaitingDestruction

Ogre::uint8 OgreOggSound::OgreOggISound::mAwaitingDestruction

protected

mBuffers

BufferListPtr OgreOggSound::OgreOggISound::mBuffers

protected

mBufferSize

size_t OgreOggSound::OgreOggISound::mBufferSize

protected

mCuePoints

std::deque<float> OgreOggSound::OgreOggISound::mCuePoints

protected

mDirection

Ogre::Vector3 OgreOggSound::OgreOggISound::mDirection

protected

mDisable3D

bool OgreOggSound::OgreOggISound::mDisable3D

protected

mFade

bool OgreOggSound::OgreOggISound::mFade

protected

mFadeEndAction

FadeControl OgreOggSound::OgreOggISound::mFadeEndAction

protected

mFadeEndVol

float OgreOggSound::OgreOggISound::mFadeEndVol

protected

mFadeInitVol

float OgreOggSound::OgreOggISound::mFadeInitVol

protected

mFadeTime

float OgreOggSound::OgreOggISound::mFadeTime

protected

mFadeTimer

float OgreOggSound::OgreOggISound::mFadeTimer

protected

Variables used to fade sound

mFormat

ALenum OgreOggSound::OgreOggISound::mFormat

protected

mGain

float OgreOggSound::OgreOggISound::mGain

protected

mGiveUpSource

bool OgreOggSound::OgreOggISound::mGiveUpSource

protected

mInitialised

bool OgreOggSound::OgreOggISound::mInitialised

protected

mInnerConeAngle

float OgreOggSound::OgreOggISound::mInnerConeAngle

protected

mLocalTransformDirty

bool OgreOggSound::OgreOggISound::mLocalTransformDirty

protected

mLoop

bool OgreOggSound::OgreOggISound::mLoop

protected

mLoopOffset

float OgreOggSound::OgreOggISound::mLoopOffset

protected

mLoopStart

float OgreOggSound::OgreOggISound::mLoopStart

protected

mMaxDistance

float OgreOggSound::OgreOggISound::mMaxDistance

protected

mMaxGain

float OgreOggSound::OgreOggISound::mMaxGain

protected

mMinGain

float OgreOggSound::OgreOggISound::mMinGain

protected

mName

Ogre::String OgreOggSound::OgreOggISound::mName

protected

mOggCallbacks

ov_callbacks OgreOggSound::OgreOggISound::mOggCallbacks

protected

mOuterConeAngle

float OgreOggSound::OgreOggISound::mOuterConeAngle

protected

mOuterConeGain

float OgreOggSound::OgreOggISound::mOuterConeGain

protected

mPitch

float OgreOggSound::OgreOggISound::mPitch

protected

mPlayPos

ALfloat OgreOggSound::OgreOggISound::mPlayPos

protected

mPlayPosChanged

bool OgreOggSound::OgreOggISound::mPlayPosChanged

protected

mPlayTime

float OgreOggSound::OgreOggISound::mPlayTime

protected

mPosition

Ogre::Vector3 OgreOggSound::OgreOggISound::mPosition

protected

mPriority

Ogre::uint8 OgreOggSound::OgreOggISound::mPriority

protected

mReferenceDistance

float OgreOggSound::OgreOggISound::mReferenceDistance

protected

mRolloffFactor

float OgreOggSound::OgreOggISound::mRolloffFactor

protected

mScnMgr

Ogre::SceneManager* OgreOggSound::OgreOggISound::mScnMgr

protected

mSeekable

bool OgreOggSound::OgreOggISound::mSeekable

protected

mSoundListener

SoundListener* OgreOggSound::OgreOggISound::mSoundListener

protected

mSource

ALuint OgreOggSound::OgreOggISound::mSource

protected

Sound properties

mSourceRelative

bool OgreOggSound::OgreOggISound::mSourceRelative

protected

mState

SoundState OgreOggSound::OgreOggISound::mState

protected

mStream

bool OgreOggSound::OgreOggISound::mStream

protected

mTemporary

bool OgreOggSound::OgreOggISound::mTemporary

protected

mVelocity

Ogre::Vector3 OgreOggSound::OgreOggISound::mVelocity

protected

---

The documentation for this class was generated from the following file:

• OgreOggISound.h
